Discontinued
ทดแทนด้วย รุ่น CM4371 (No analog output) หรือ CM7290+CT7636 (with analog output)
20A/200A AC/DC Clamp Meters with Analog Output and Peak Hold for Inrush Measurement Applications
Hioki clamp meters are best-in-class measuring devices incorporating Hioki’s expertise in current sensing technology. The 3284 is an AC/DC current and voltage clamp meter with analog output capabilities and a peak hold function.
DC Current range: |
20.00/ 200.0 A, Basic accuracy: ±1.3 % rdg. ±3 dgt |
AC Current range: |
20.00/ 200.0 A (10 Hz to 2 kHz, True RMS), |
DC voltage range: |
30.00 V to 600 V, 3 ranges, Basic accuracy: ±1.0 % rdg. ±3 dgt. |
AC voltage range: |
30.00 V to 600 V, 3 ranges (10 to 1 kHz, True RMS), |
Crest factor |
2.5 or less (1.5 at 200 A, 1.7 at 600 V) |
Monitor, Analog output | DC, or AC 1 V/ f.s., Level output, Waveform output: DC to 20 kHz bandwidth (±3dB) |
Resistance, Continuity check: |
N/A |
Frequency range: |
1.00 Hz to 1000 Hz, Basic accuracy: ±0.3 % rdg. ±1 dgt. |
Other functions: |
AC+DC mode, Maximum/ Minimum/ Average value record function, Data hold, Peak hold, Auto power off, Auto zero |
Display: |
Display refresh rate: 4 times/s (FAST), 1 time/3s (SLOW), 4 times/s (bar graph) |
Power supply: |
6F22 (Stacked manganese battery) ×1, Continuous use: 25 hours, or AC adapter 9445-02/-03 |
Core jaw dia: |
φ 33 mm (1.30 in) |
Dimensions and mass: |
62 mm (2.44 in) W × 230 mm (9.06 in) H × 39 mm (1.54 in) D, 460 g (16.2 oz) |
Accessories: |
Test Lead L9207-10 ×1, Carrying Case 9399 ×1, Hand strap ×1, 6F22 (Stacked manganese battery) ×1, Instruction manual ×1 |
Catalog: CLAMP METER Series Download PDF
Instruction Manual Download PDF
