Type: Regulated switched-mode power supply.

Input Voltage: 100-240 V AC (single-phase) or 127-370 V DC.

Output Voltage: 24 V DC (adjustable from 21.6 to 27.6 V).

Output Current: 5 A.

Output Power: 120 W.

Efficiency: Up to 87%.

Mounting: Designed for DIN rail mounting (35 mm symmetrical DIN rail).

Protection:

• Overload: 1.1-1.3 times the rated current (In​).

• Overvoltage: Trips if output voltage exceeds 29-33 V.

• Short-circuit: Automatic reset.

• Thermal: Automatic reset.

Indicator: A green LED on the front indicates the output voltage status.

Connections: Screw terminals for input, output, and ground.

Safety and Standards: Meets standards like CE and UL. It has an IP20 protection rating.
